Mechanical Grooved Tee
Application: Branching connection without welding
Finish: Painted, Anti-Corrosion Coated
Origin: China
Manufacturing Process: Casting, Machining
Certification: ISO9001, CE
Mechanical Grooved Tee for Branch Piping: Ductile Iron and Carbon Steel Fitting for Weld-Free Connections
FLA Industrial & Trading Co., Ltd. supplies branch fittings in ductile iron and carbon steel. The Mechanical Grooved Tee is one item in that range. It makes a branch connection with no welding. Each tee is cast first, then machined. Painting and an anti-corrosion coating come after that. The grooved ends mate with mechanical couplings, not welds. Certifications listed are ISO9001 and CE. Standard demand is covered by 2,000 tons of inventory. Custom special-shaped parts ship in 7–15 days. Ask for pricing, unit weight or a 3D design and you get an answer in 24–48 hours.
Overview
On grooved mechanical piping, the grooved tee is the three-way fitting. Cast or roll-groove profiles sit on its ends and lock into mechanical couplings. The joint needs no weld seam and no thread. One line can be split into two with it, or two flows merged into one.
With no weld in the joint, the fitting can work on sites where hot work is limited. Chemical plants and occupied buildings are two examples. Site rules and the project specification still need checking every time.

Key Features and Benefits
Branch connections get easier with this product. That is why people choose it when welding is hard, limited, or slow.
- No welding at the joint: Grooved ends are joined with mechanical couplings. So the branch joint stays unwelded. Other work on site may still need permits, so check the local rules.
- Coupling choice matters: Flexible couplings can take up some pipe movement. A rigid coupling holds the line tighter. Choose the coupling type that matches your system design.
- Easier assembly: Putting parts together takes less time with mechanical joints than with welding or flanging. Pipe size changes how much time you save. Crew skill plays a part as well. Site conditions count too.
- Access for maintenance: Take off the couplings. Your team can then open the junction to inspect or repair it.
Specifications
| Model | Model |
|---|---|
| DN50×DN25 (60×33) | DN100×80 (114×89) |
| DN65×25 (76×33) | DN125×25 (140×33) |
| DN65×32 (76×42) | DN125×32 (140×42) |
| DN65×40 (76×48) | DN125×40 (140×48) |
| DN65×50 (76×60) | DN125×50 (140×60) |
| DN80×DN25 (89×33) | DN125×65 (140×76) |
| DN80×DN32 (89×42) | DN125×80 (140×89) |
| DN80×DN40 (89×48) | DN150×25/32/40/50 (OD 165) |
| DN80×DN50 (89×60) | DN150×65 (165×76) |
| DN100×25 (114×33) | DN150×80 (165×89) |
| DN100×32 (114×42) | DN200×25/32/40 |
| DN100×40 (114×48) | DN200×50/65 (219×60×76) |
| DN100×50 (114×60) | DN200×80 (219×89) |
| DN100×65 (114×76) |
The product data we have now leaves out the size range. Pressure rating is missing too. So are groove dimensions and unit weight. You will not find coating type or thickness here. Dimensional tolerances are absent as well. None of those values appear here. Want to confirm them for This product? Send your size, pressure rating and pipe schedule with your inquiry. Before production starts, we check the material. We check performance too. Dimensional accuracy gets checked as well.

Materials, Process and Finish
The tee body gets its shape from casting. Ductile iron works for this part. Carbon steel works too. Next comes machining, which cuts the groove and the end profiles. Last, a paint coat goes on, along with an anti-corrosion layer. Need a special coating type or a rating for buried service? Tell us early. We will confirm what we can supply.

Applications
HVAC lines use this fitting. Fire protection and mining pipelines use it too. Chemical plants and finished buildings choose it as well, because welding there adds risk. Need a three-way point for splitting fluid flow without welded branch joints? A Mechanical Grooved Tee fits that job.
- HVAC: Connects branch lines to a main line in building piping.
- Fire protection: You get a branch connection for fire protection piping with this item. Before you order, check the approvals your project needs.
- Mining pipelines: A branch point sits there. When the line needs an inspection, open it at the coupling.
- Chemical plants and finished buildings: The joint calls for no welding. In hazardous areas, or in rooms people already use, that counts for a lot.

Inspection Points for Buyers
Before you order, ask for the items listed below. Your project's checks come next, and you should agree on which ones it needs.
- Groove dimensions: Your project names a standard, for example AWWA C606 where it applies. Measure the grooves against it. A groove cut wrong leads to leaks, or to trouble with the coupling.
- Surface condition: Look over the casting. Sand holes, cold shuts and heavy porosity are the things to watch for. Coating has to be intact.
- Material: Ask if this order is ductile iron or carbon steel. Then request the material documents your project calls for.
- Pressure requirements: Tell us the working pressure, plus any test requirements. That way we can confirm them before production starts.
Related Option for Mechanical Grooved Tee Outlet
A mechanical tee grooved outlet is a different product type. This one is a clamp-style fitting. It bolts around the pipe and adds a branch over a hole cut in the pipe wall. Retrofits are where it works well, since the main pipe does not have to be cut into sections. Not sure which type fits? Send us your layout.
Customization and Technical Support
FLA makes custom special-shaped parts. We also do non-standard sizes and special structures. These go to machinery, building materials and other industries.
- Before production: Custom parts start with mold development. We also handle 3D design and verification, so you get a chance to review the product form.
- During production: Layout optimization and confirmation of material, performance and dimensional accuracy.
- Before delivery: Production progress updates matched to delivery progress.
Custom special-shaped parts, including the Mechanical Grooved Tee, can be delivered in 7–15 days. Standard demand is supported from 2,000 tons of inventory.
FAQ
Q: Does a grooved tee need welding?
A: No. The grooved ends join with mechanical couplings, so the branch joint is made without welding.
Q: What materials are available?
A: Casting and machining turn ductile iron or carbon steel into the tee. Paint and an anti-corrosion coating go on after that.
Q: What should I send for a quote?
A: Send the size, pressure rating, pipe schedule, quantity and any drawings. Pricing, unit weight and 3D design requests receive a reply within 24–48 hours.
Q: Which certifications are listed?
A: ISO9001 and CE are the certifications we list. Some projects need other approvals, for fire protection, drinking water or marine use. Send us the requirement and we will tell you what can be confirmed.
Q: Can I confirm pipe compatibility or buried service?
A: These details are not listed in the current product data. Send your pipe outer diameter, schedule, operating pressure and installation environment, and we will confirm before production.
Q: How fast can you deliver?
A: Standard demand is supported from 2,000 tons of inventory. Custom special-shaped parts can be delivered in 7–15 days.
Contact Us
Send your size, pressure rating, quantity and drawings to sales@flaindustrial.com for a Mechanical Grooved Tee quote. We reply to pricing, unit weight and 3D design requests within 24–48 hours.
